The OND Drum Diffuser is designed to deliver air homogeneously into comfort zones in spaces with high ceilings and large areas such as sports complexes, airports, atriums, and factories.
Description
Material and Usage Features
The diffuser body is suitable for horizontal air discharge applications, offering flexible air direction with the ability to rotate ±30° on the horizontal axis. Additionally, the manually adjustable blades allow for the discharge air’s flow characteristics to be adjusted for summer and winter conditions, enabling conditioned air to be directed to hard-to-reach areas. The diffuser’s casing, body, and blades are made from specially extruded aluminum profiles. Standard finishes include electrostatic powder coating in RAL 9010 and RAL 9016. Upon customer request, the diffuser can be produced in other RAL colors, matte aluminum anodized, or raw finish. When airflow adjustment is required, an opposed blade damper, color-matched to the product, can be controlled with a special damper key. Unless otherwise specified at the time of order, the OND Drum Diffuser is produced with standard features.
Dimensions:
- W: 200…2300 (mm)
- H: 165 (mm)
Features:
- Decorative design
- Long throw distance
- Aluminum profile construction
- Adjustable for summer and winter positioning
